It LIVES.
It will soon get plastic surgery, but... IT LIIIIIIIIIIIIVES!!!
Apologies for the photo, I don't have a memory card here so it's the old-school phone camera. I don't have a fancy new phone with a great camera, so I had to paste together two separate photos. ![]()
This is the current test setup for my proper powerlifting squats!
I used 2x6x4 pieces for the frame, and some plywood that used to be part of my body lever/ NLC set up before I came up with a better one. There's also a piece of either 1 or 1.25" Schedule 40 that is the current anchor for the bands. Because of the short levers involved, it's totally fine. I'm still going to replace it with metal, because metal is shiny and looks professional, but in terms of pure utility it is functional. As you can obviously see.
The squat box is two cinder blocks on top of two other cinder blocks. Total height is 16". It is ROCK SOLID. The top layer is offset from the bottom layer by 90 degrees for stability, as you can see. The box is angled the way it is because that makes approaching and using the box easier and more intuitive. It also allows for a wider variety of foot positions, if you're into that kind of thing. I'll take a side photo to show bottom depth when I have a real camera again.
Total cost was 29 dollars. Total construction time was ~20 minutes.
Tools required: 1.5" paddle wood-boring bit, power drill, saw, screws, hammer (for making the inner pipe channels after cutting with the saw and screwing the frame together.
The plywood is currently only attached over the pipe, as that is where I need it ATM. I will do a weight check later on to see what the top and bottom band resistance is.
I'll tell you this: At the top it's HEAVY. I love it! Feels incredible... way better than doing separate heavy partial-range work.
